TP-4800

Description

TP-4800 Black Maxx is the severe-chemical grade in the sealing compound range, developed for aggressive fluids where general-purpose packing materials may suffer chemical attack, hardening, swelling, or accelerated wear. Official Tom-Pac information describes TP-4800 as a full-spectrum compound with pH 0–14 capability, intended for chemicals and pulp mill black liquor, while retaining the same online injection and no seal water maintenance philosophy used across the product family.



This grade is best targeted at chemical processing, pulp and paper recovery areas, petrochemical plants, refineries, wastewater chemical dosing systems, acid / caustic transfer, solvent-handling equipment, and other non-hazardous or controlled-risk aggressive-fluid duties where plant engineers require simplified sealing without continuous gland water. For hazardous, toxic, volatile, or emission-critical services, a formal risk review against mechanical seal alternatives remains necessary.



Technical Key Features

• No moving sealing components inside the stuffing box.

• Full-spectrum chemical resistance for pH 0–14 service range.

• Online resealing capability to reduce shutdown-related maintenance.

• Designed for acids, solvents, harsh chemicals, and pulp mill black liquor.

• Reduces sleeve wear compared with conventional compression packing.

• Maintains compound flexibility; product literature states it will not dry or harden.

• Self-lubricating and self-cooling compound with no continuous seal water requirement.



Service Overview

Parameter	Value
Equipment	Chemical process pumps, pulp mill pumps, agitators, mixers, valves, dosing, and transfer equipment
Fluid	Acids, caustics, solvents, aggressive chemicals, pulp mill black liquor, and chemically severe process fluids
Service Nature	Corrosive / chemically aggressive dynamic and static stuffing box sealing
Operating Mode	Continuous service with online injection maintenance; initial fill by hand



Specifications;

Item	Min	Max	Typical / Notes
Size	On Request	On Request	Suitable for packed stuffing boxes; fill volume depends on stuffing box geometry
Pressure	Atmospheric	15 bar (200 psi nominal) dynamic / 75 bar (1050 psi) static	Dynamic pressure limit for pumps; static limit for valve applications
Temp	-40°C (-40°F)	+210°C (+410°F) dynamic / +230°C (+450°F) static	Confirm chemical compatibility at operating temperature
Speed	—	2400 RPM	Recommended maximum for pumps and dynamic applications
Fluid Compatibility	pH 0	pH 13	Severe chemical range



Materials

Component	Standard Material	Optional Material	Comment
Sealing Compound	TP-4800 Black Maxx chemical-resistant compound	TP-4000 or TP-5400 by service	TP-4800 is preferred for severe chemical exposure
End Rings	Chemical-compatible braided packing	Graphite or specialty braid by fluid	End-ring compatibility must match the chemical duty
Injection Interface	9.5 mm (3/8”) NPT unrestricted port	Stainless steel injection pipe/tube	Avoid reducers and sharp elbows to maintain compound flow
Loader System	TP-8100 Linear Loader™	Project-specific injection system	Catalogue notes TP-8100 only for TP-4800 injection service



Applications

• Valves in static chemical service requiring flexible, non-hardening sealing.

• Wastewater and effluent-treatment pumps exposed to variable pH fluids.

• Mixers and agitators in chemical blending, reaction, and neutralization systems.

• Petrochemical and refinery utility pumps where chemical compatibility is required.

• Process equipment where flush water elimination reduces dilution and effluent load.

• Pulp and paper pumps handling black liquor and chemically aggressive liquor streams.

• Chemical process pumps handling acids, caustics, solvents, and process intermediates.



Operating Limits

Parameter	Value
Pressure	Up to 15 bar (200 psi nominal) dynamic; up to 75 bar (1050 psi) static
Temp	-40°C to +210°C (-40°F to +410°F) dynamic; -40°C to +230°C (-40°F to +450°F) static
Speed	Up to 2400 RPM
Size Range	Stuffing box size/shaft size: On Request; requires suitable packed stuffing box geometry
pH Range	0–13
