Double Cartridge Mechanical Seal (Face-to-Back Arrangement)

High-Performance Face-to-Back Arrangement Double Cartridge Mechanical Seal

Our Face-to-Back Arrangement Double Cartridge Mechanical Seal is designed to provide superior sealing performance in critical industrial applications. This high-performance seal is preassembled with a gland plate on a sleeve, enabling seamless installation over the pump shaft or shaft sleeve in conventional stuffing boxes, making it compatible with a wide range of pump types and manufacturers.

The Face-to-Back configuration combines the advantages of both back-to-back and face-to-face arrangements, ensuring efficient leakage control and an enhanced pressure barrier. This design is particularly suited for applications handling hazardous, toxic, or high-pressure media, preventing contamination and ensuring long-term equipment reliability.

For optimal operation, the seal must be installed at its correct operating length and positioned precisely within a clean housing. The cartridge construction allows for quick installation and easy removal, minimizing downtime and eliminating the need for highly skilled labour.

With its robust, factory-assembled design, our Face-to-Back Arrangement Double Cartridge Mechanical Seal delivers a highly efficient, durable, and maintenance-friendly sealing solution for demanding industrial environments.

Features;

• Double Seal: Ensures enhanced sealing reliability and leakage prevention.
• Cartridge Construction: Preassembled design for easy installation and removal.
• Available in Metric and Inch Sizes: Compatible with different pump specifications.
• Quick Installation & Easy Removal: Reduces downtime and simplifies maintenance.
• Flushing & Quenching Connections: Enhances cooling, lubrication, and seal longevity.
• Multiple & Wave Spring Type: Suitable for various applications and operating conditions.
• Factory Assembled & Tested: Guarantees quality, reliability, and performance consistency.
• Independent of Shaft Rotation Direction: Offers versatile application across different pump types.
• Rotating Multiple Spring Design: Ensures uniform pressure distribution for improved sealing efficiency.
• Face-to-Back Arrangement: Ensures effective sealing by combining the advantages of both back-to-back and face-to-face configurations.

Specification;
